Buyers Products H5036201 – Hydraulic Gear Pump With 7/8-13 Spline Shaft And 2 Inch Diameter Gear

Built tough of cast iron with teflon-coated bronze thrustplates. Structural integrity supported by four internal dowels and a shaft bearing. High-pressure rated. The H50 Series Hydraulic Gear Pump with Spline Shaft from Buyers Products is a sturdy, heavy duty bi-rotational pump that can be 2- or 4-bolt mounted in an SAE B mount. Choose from a range of models to meet your needs. All models feature a 7/8 inch by 13 spline shaft.   Displacement 5 Cubic Inches Displacement 20 GPM Gear Width 2 Inches Input Mount Type Integral Bracket Material Cast Iron Maximum Rotations Per Minute (RPM) 2000 RPM Mount Type SAE B 2/4 Bolt Pilot Diameter 4 Inches Shaft Size 7/8-13 Shaft Type Splined Ports (Rear/Side) Rear/Side Inlet Port Size 1-1/4 NPT Maximum Pressure 2500 PSI Direct Or Remote Mount Direct Mount Outlet Port Size 1-1/4 NPT Rotation Bi-Directional Gear Size 2 Inches Flow At 600 RPM 12 GPM Flow At 1000 RPM 20 GPM Flow At 1800 RPM 36 GPM Flow At 900 RPM 18 GPM Flow At 1200 RPM 24 GPM Flow At 1500 RPM 30 GPM Flow At 2100 RPM 42 GPM Rear Port Size 1-1/4 NPT Min Order Qty 1 Multiple Sale Qty 1 Product Code 620 Sell Pack Type Box Shipping Weight 49 Lbs UPC 724920109185   Product Common Use: Truck and Trailer Hydraulic Systems
