Membrane Switch Matrix Keypad 12 16 Keys

Item Name: Membrane Switch Matrix Keypad 12 16 Keys Specification: – Contact resistance: 500 ohms – Insulation resistance: 100M ohms – Key Operating Force: 150-200N – Rebound time: 1 (ms) – Push button Life: 100 million (times) – Operating Temperature: -40c ~ 60c – Circuit Rating: 35V (DC), 100mA, 1W – Contact resistance: 10 ohms ~ 500 ohms – (Varies according to the lead lengths and different from those of the material used) – Dielectric Strength: 250VRms (50 ~ 60Hz 1min) – Electric shock jitter: <5ms – 8 Pins Dupont 2.54mm Connector Feature: Thickness: 78 x 70mm, self-adhesive sticker PCs in Item: 1 PC Manufacturer: N/A, Made in China Note:
