DEFUM AD125 horizontal drilling and milling machine

The DEFUM AD125 horizontal drilling and milling machine was produced in 1978. The boring machine allows you to process details with a maximum weight of up to 10 tons, and the X / Y / Z travels are 1600, 2000 and 1500 mm, respectively. The machine is equipped with: vertical milling head, facing disc, boring bars, steady rest and four boring shafts. It also has a table with dimensions (L x W) 1500 x 1800 mm. The machine is fully operational and ready to work. Technical data of a horizontal drilling and milling machine DEFUM AD125 – travels (X / Y / Z): 1600/2000/1500 mm – table dimensions (length x width): 1500 x 1800 mm – maximum table load: 10 tons – spindle diameter: fi 125 mm – spindle extension: 900 mm – maximum planning diameter: fi 1200 mm Equipment for the DEFUM AD125 horizontal drilling and milling machine – boring shafts: 4 pcs. – she bored – steady rest – vertical milling head – planning disc
